      6AV6643-0AA01-1AX0
      • 6AV6643-0AA01-1AX0
      • 6AV6643-0AA01-1AX0
      • 6AV6643-0AA01-1AX0

      6AV6643-0AA01-1AX0

      ★ ★ ★ ★ ★ 4.9 2983 Reviews

      Model: 6AV6643-0AA01-1AX0

      Order No:

      SKU: 10000003220601

      Category: SIEMENS

      Brand: SIEMENS

      Condition: New Sealed Under Guarantee

      Size: 0.00cm, 0.00cm, 0.00cm; Diam:0.00cm

      Weight: 2.00kg

      Product Selection Engineer: wuShengpeng

      Leading

      Shipping

      QTY
      - +

      Customer Service Guarantee

      100% secure payment

      Quality Guarantee

      No Reason Returns

      You May Also Like

      Selling List

      Description Reviews
      6AV6643-0AA01-1AX0 TP 277 6"
      Artikelnummer6AV6643-0AA01-1AX0
      SIMATIC TP 277 6" TOUCH PANEL 5.7" TFT DISPLAY 4 MB CONFIGURING MEMORY, CONFIGURABLE WITH WINCC FLEXIBLE 2005 STANDARD OR HIGHER ******************************* THIS PRODUCT IS NO LONGER AVAILABLE FROM OCT. 1ST, 2014. INFORMATION ABOUT SUCCESSOR SEE SIMATIC UPDATE ID: 62977695 FOR FURTHER QUESTIONS PLEASE APPROACH YOUR SIEMENS CONTACT PERSON.
      General information
      Customer-specific configurationYes
      Display
      Design of displayTFT
      Screen diagonal5.7 in
      Size5.7"
      Display typeTFT, 256 colors
      Color typeColors
      Resolution (pixels)
      ● Horizontal image resolution320
      ● Vertical image resolution240
      ● Resolution (WxH in pixel)320 x 240
      Backlighting
      ● MTBF backlighting (at 25 °C)60 000 h
      Control elements
      Control elementsTouch screen
      Operating optionsTouch
      Connection for mouse/keyboard/barcode readerUSB / USB / USB
      Keyboard
      ● Keys with LEDNo
      ● Numeric/alphabetical inputYes / Yes
      — hexadecimal keyboardYes
      Touch operation
      ● Design as touch screenYes
      Supply voltage
      Type of supply voltageDC
      Processor
      ProcessorRISC 32-bit
      Memory
      Usable memory for user data4 Mbyte
      Main memory
      ● Capacity of main memory, maximum64 Mbyte
      Time of day
      Clock
      ● TypeSoftware clock, synchronizable, no battery backup
      ● Hardware clock (real-time clock)No
      ● Software clockYes
      ● Battery-backedNo
      ● SynchronizableYes
      Interfaces
      Interfaces1 x RS422, 1 x RS485, 1 x Ethernet (RJ45)
      Number of RS 485 interfaces1
      USB port1 x USB
      Multi Media Card slot1x Multimedia Card slot, up to 128 MB
      Industrial Ethernet
      ● Industrial Ethernet interface1 x Ethernet (RJ45)
      Degree and class of protection
      FrontIP65, NEMA 4x (when installed)
      IP (at the front)IP65
      IP (rear)IP20
      Standards, approvals, certificates
      CertificationsCE, UL, NEMA 4x
      Suitable for safety functionsNo
      Ambient conditions
      Mounting positionvertical
      Operating temperature
      ● Operation0 °C to +50 °C
      Storage/transport temperature
      ● Transport, storage-20 °C to +60 °C
      Relative humidity
      ● Operation, max.80 %
      Operating systems
      Operating systemWindows CE
      Configuration
      Message indicatorYes
      With alarm logging system (incl. buffer and acknowledgment)Yes
      Process value display (output)Yes
      Process value default (input) possibleYes
      Recipe administrationYes
      Configuration software
      ● STEP 7 Basic (TIA Portal)No
      ● STEP 7 Professional (TIA Portal)No
      ● WinCC flexible CompactNo
      ● WinCC flexible StandardYes
      ● WinCC flexible AdvancedYes
      ● WinCC Basic (TIA Portal)No
      ● WinCC Comfort (TIA Portal)Yes
      ● WinCC Advanced (TIA Portal)Yes
      ● WinCC Professional (TIA Portal)Yes
      ● Configuration toolWinCC flexible Standard Version 2005 SP1 or higher (to be ordered separately)
      ● 2nd configuration kitWinCC flexible Standard
      — VersionVersion 2005 SP 1
      — Configuration toolWinCC flexible
      — TypeStandard
      Languages
      Online languages
      ● Number of online/runtime languages16
      Languages
      ● Languages per project32
      Functionality under WinCC (TIA Portal)
      LibrariesYes
      Task plannerYes
      Help systemYes
      ● Number of characters per info text80
      Message system
      ● Number of alarm classes32
      ● Number of messages4 000
      ● Bit messagesYes
      ● Analog messagesYes
      ● Number of bit messages4 000
      ● Number of analog messages4 000
      ● System messages HMIYes
      ● System messages PLCYes
      ● System messages, other (SIMATIC S7, Sinumerik, Simotion, etc.)Yes
      ● Message length (in characters)80
      ● Lines1
      ● Number of process values per message8
      ● Acknowledgment groupsYes
      ● Message indicatorYes
      ● First/last valueYes
      Recipe administration
      ● Number of recipes300
      ● Data records per recipe500
      ● Entries per data record1 000
      ● Recipe memory64 KB integrated Flash, expandable (using optional memory card)
      Variables
      ● Number of variables per device2 048
      ● Number of variables per screen200
      ● Number of variables1 000
      ● Limit valuesYes
      ● MultiplexingYes
      ● StructsYes
      ● Type Date & Time2 048
      Images
      ● Number of configurable images500
      ● Permanent window/defaultYes
      ● Start screen configurableYes
      ● Image selection by PLCYes
      ● Image number in the PLCYes
      Image objects
      ● Text objects10,000 text elements
      ● Fields per image200
      ● Date/time fields200
      ● ReturnYes
      ● Graphics objectBit maps, icons, vector graphics
      — Icons1 000
      Complex image objects
      ● Status/controlWith SIMATIC S7
      ● dynamic objectsDiagrams, bar graphs, sliders, analog display, invisible buttons
      — Number of objects per project1 000
      — Number per image10
      ● MethodsTrend / profile
      ● Limit value linesYes
      ● Number of bars per chart10
      ● Limit value linesYes
      ● alphanumeric fields300
      ● alphanumeric fields per image200
      ● numerical fields2 048
      ● numerical fields per image200
      ● Password errors2 048
      ● Number of slides per image10
      ● Number of analog indicators per image10
      ● Number of visible switches per project200
      ● visible switches per image200
      ● hidden switches per image200
      ● Number of status switches per project200
      ● Button status switches per image200
      ● Number of selector switches per project200
      ● Selector switches per image200
      ● Number of decade switches per project200
      ● Decade switches per image200
      ● Number of signal lamps per project200
      ● Signal lamps per image200
      Attributes for dynamic objects
      ● Color changeYes
      ● X/Y movementYes
      ● HideYes
      Lists
      ● Number of text lists per project500
      ● Number of text lists per image200
      ● Number of entries per text list256
      ● Number of graphics lists per project400
      ● Number of graphic lists per image200
      ● Number of entries per graphics list256
      Archiving
      ● Number of archives per device20
      ● Number of measuring points per project20
      ● Number of entries per archive10 000
      ● Message archiveYes
      ● Process value archiveYes
      ● Archiving methods
      — Sequential archiveYes
      — Short-term archiveYes
      ● Memory locationMultiMediaCard
      — EthernetYes
      ● Data storage format
      — CSVYes
      ● Online evaluation
      — via trendsYes
      Filters
      ● cyclicYes
      ● ToleranceYes
      ● ChangeYes
      Security
      ● Number of user groups50
      ● Number of user rights32
      ● Password export/importYes
      Logging through printer
      ● Recording/PrintingAlarms, report (shift report), color print, hardcopy
      Transfer (upload/download)
      ● Transfer of configurationMPI/PROFIBUS DP, USB, Ethernet, automatic transfer recognition
      Process coupling
      ● Connection to controllerS5, S7-200, S7- 300/400, TI 505, SINUMERIK, SIMOTION, Allen Bradley (DF1), Allen Bradley (DF485), Mitsubishi (FX), Telemecanique (ADJUST), OMRON (LINK/Multilink), Modicon (Modbus), see section on "System interfaces"
      ● S7-1200Yes
      ● S7-200Yes
      — PPI (point-to-point)Yes
      — PPI networkYes
      — MPIYes
      — PROFIBUS DPYes
      — EthernetYes
      ● S7-300/400Yes
      — MPIYes
      — PROFIBUS DPYes
      — PROFINETYes
      ● S5Yes
      — serialYes
      — PROFIBUS DPYes
      ● TI 505Yes
      ● Allen Bradley (DF1)Yes
      ● Allen Bradley (DF485)Yes
      ● Mitsubishi (FX)Yes
      ● Mitsubishi (MP4)Yes
      ● Telemechanique (ADJUST)Yes
      ● Telemecanique (Uni-Telway)Yes
      ● OMRON (LINK/Multilink)Yes
      ● Modicon (Modbus)Yes
      ● GE-Fanuc (SNP)Yes
      Functions
      ● TAB sequenceYes
      ● Calculating functionsYes
      ● AnimateYes
      Service tools/configuration aids
      ● Clean screenYes
      ● Touch calibrationYes
      ● Backup/restoreYes
      ● SimulationYes
      ● Device switchoverYes
      ● Delta transferYes
      Expandability/openness
      ● Open Platform ProgramYes
      I/O / Options
      I/O devicesPrinter, barcode reader
      ● MultiMediaCardYes
      Additional software components loadableYes
      Dimensions
      Width of the housing front212 mm
      Height of housing front156 mm
      Mounting cutout/device depth (W x H x T)197 mm x 141 mm / 45 mm device depth
      Weights
      Weight (without packaging)0.78 kg
      other
      free hotlineYes
      Warranty period1 y
      last modified:25.09.2014
      ">
