Sensing distance 1 to 7m
Light source Infrared LED(850nm modulated)
Optical axis pitch 80mm
Number of optical axes 14
Sensing height 1,040mm
Power supply 12-24VDC ±10%(ripple P-P: max. 10%)
Control output NPN open collector
Operation mode Dark ON
Environment_Ambient illumination Ambient light: Max. 100,000lx(receiver illumination)
Environment_Ambient temperature -10 to 55℃, storage: -20 to 60℃
Connection type Cable connector type(Ø5, 300mm, M12)
Protection structure IP67(IEC standard)
Korean Railway Standards KRS SG 0068
Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH
Min. sensing target Opaque material of min. Ø90mm
Response time Max. 50ms
Material Case: Aluminum, Sensing part and indicator: Acrylic
Cable specification Ø5mm, 4-wire, 300mm, M12 connector
Accessories Bracket A: 4, Bracket B: 4, Fixing bolt: 8
Weight Approx. 2.1kg(approx. 1.7kg)(based on BWC80-14H)
