The Star shifting interface converter products include three major series:
Industrial serial optical fiber converter can convert the industrial site RS232/485/422 serial electrical signal into optical fiber signal transmission, to achieve long-distance transmission requirements, improve signal anti-interference ability;
Industrial serial cable converter, to achieve the industrial site RS232 and RS485/422 signals between the conversion, as well as multiple serial bus concentrator function, provide active/passive, isolated/non-isolated and other types of choice;
Industrial serial port repeater can realize the isolation relay function of RS232/485/422 signal in industrial field. By isolating and amplifies the signal, it can extend the communication distance and anti-interference.
● Support 1 way RS232/485 to 4 way RS485
● Industrial-class design, preferably imported components
● Communication distance 1.5km, support 512 nodes
● Automatic identification of RS485 signal flow direction, zero delay automatic forwarding
● signal line 600W/ms lightning protection and 15KV anti-static protection, 2.5KV optical isolation
Technical parameters | |
Standard | Compliant with EIA RS-232, RS-485, RS-422 standards |
Interface | |
Interface form | Industrial terminal block |
Communication rate | |
Baud Rate | 300bps～115.2kbps |
LEDs | |
Power indicator | POW(Red): Always lit when the power is connected normally |
Serial port transceiver indicator light | ︾(Green): Flashes when data is being sent or received ︽(Yellow): Flashes when data is being sent or received |
Power | |
Power Supply | External DC5V power supply, external DC9~30V power supply |
Interface | Industrial terminal block |
Physical Characteristics | |
Shell | DIN rail shell |
Dimension | 123mm×34mm×72mm |
Weight | 0.13kg |
Transmission distance | |
Serial port line | RS-232, 15m@9600bps RS-422/RS-485, 1.2km@9600bps |
Working Environment | |
Operating Temperature | -40°C~85°C |
Storage temperature | -40°C~85°C |
Ambient Humidity | 5%~95% |
